Mercedes ML (W164) Rear 12V Socket: The Case of the Self-Healing Fault

​I recently went on a road trip with family, and while the ML handled the whole journey admirably, there was one small failure that really niggled at me.

​In the grand scheme of things, it was a minor annoyance, but still a pain to say the least — the rear seat passengers couldn’t charge their phones. The horror!

Range Anxiety

​Now, the problem wasn’t that their phones actually died, but rather the sheer anxiety of the what if. A kind of range anxiety, if you will — a common modern affliction, and one I got to witness firsthand.

​All went well on our short trip around Ohio. No one actually ran out of battery power, but as soon as I got back to the workshop, the first thing I did was dig into this socket issue.

The Diag Part

​I did as I normally do: set myself up with all the tools to get the job done, printed off a few fuse diagrams, did a little homework on the circuit, and set to work. I even set up the camera along with my newly acquired DJI Mic Mini to make a proper vlog-style video of the fix.

​My hopes of making a detailed, step-by-step diagnostic video came crashing down about 10 minutes into filming when, after a couple of basic checks, the socket simply started working again.

So. What Happened Here?

​Cue the questions every mechanic asks themselves:

  • ​Was it a bad connection that I disturbed? No, I don’t think so — I hadn’t poked around too hard yet.
  • ​Did the fuse have oxidized contacts? Very possibly — I did feel I saw something happen when I was testing the fuse with my test light.
  • ​Was the Rear SAM module to blame? Did plugging into the cargo socket somehow kick it back into life?
  • ​Or was there just a spot of surface corrosion inside the rear socket barrel that cleared the moment I pushed the test probe in? — There was evidence that the plug was not making great contact in that socket, but I dont believe it was the main culprit.

​I can’t answer any of those questions for certain — but right now I’m blaming my test light poking.

​So far, it’s still powering up fine. I’ll keep an eye on it until the day it decides to act up again.



Snap-on Software expiry notice and how to fix it

I went to use my Snap-on Verus D10 the other morning and was faced with a software expiry warning and it failed to launch the diagnostic suite. Yes this is an older tool but it’s still incredibly handy and plugs into a lot of my clients vehicles. Plus the scope and multimeter functions are nice to have as they work quite well.

Searching online revealed others having this very same issue. While quite a few of them were changing the time/date in the BIOS back to 2019 or similar, I didn’t want to do that if it could be avoided. Doing a little more digging on Google and diag.net eventually led me to the correct path to resolve the issue, but there were a few turns along the way.

Here’s how I did it

You need to allow hidden files and folders to be seen. If like me, you have a Windows XP machine here’s how you do it,

  1. Click Start and open My Computer (or open the Control Panel).
  2. From the menu bar at the top, click Tools, then select Folder Options.
  3. Click the View tab.
  4. Under the Hidden files and folders section, select the radio button for Show hidden files and folders.
  5. (Optional) To view system files as well, uncheck Hide protected operating system files (recommended) and click Yes to confirm the warning.
  6. Click Apply and then OK to save the changes.
  • Go to the Snap-on drive where the diagnostic suite is loaded, usually D:\ drive, and open it.
  • Remove the original setup file, then load this new file. If you just double click the downloaded file it will tell you that a newer version of this file exists and abort the operation

Some Issues

This worked for me and is still working, however it sometimes freezes when it is booting up. Mostly just requiring a shutdown and restart, but a few times I have had to remove the battery. I believe this is a usual windows update phonemon and I haven’t found a fix as of today. It’s a bit of a pain but when the tool boots up it works without issue. So far anyway.

Video

If you want to see me do this in real time watch the video. I’m new to video making so I did fumble through this but I eventually got to a fix and a test of the tool. I’m (somewhat) enjoying the process of making videos and realizing how hard it is to make something coherent, But I intend to continue and surely I can only get better!

A Look Around The Workshop

In an effort to get more comfortable picking up my camera I did a quick walk around my in progress car repair workshop.

I just picked up the camera, no script, nothing really thought out about how I was going to do it, the goal was to just talk and look around.

Hopefully this is the first of many times I do this, as I do intend to have a YouTube presence with my new venture, going forward.
